5 core 150 mm² STA armoured cable has an additional protective layer to maintain it far from undesirable cut or damage. The armour made of aluminium tapes placed under the sheath to protect the conductor, and insulate the layers.or strings that protect the conductors from external forces. It also avoids any internal abnormalities from causing the release of dangerous energy levels to the outside in environments.The STA cable can also be described to mains cable, power cable, armoured cable and booklet-armoured cable. With copper wiring creating the perfect conductors for the core with a range of types for example, 2 core, 3 core and 5 core STA Cables to name a few.
We provide a comprehensive series of BASEC-approved armoured cables, manufactured in accordance with a number of British, European and International standards including BS5467, BS6622, BS6724, BS7835, BS EN 50267, IEC 60502 and BS EN 60332-1-2 (for single core cables). Huadong Cables’ range of armoured cable is offered with a Copper (Cu) or Aluminium (Al) conductor and with a Polyvinyl Chloride (PVC) or Low Smoke Zero Halogen (LSZH) sheathing, LSZH sheathings are recommended for use in high density enclosed areas, and are obligatory in some social places.
Due to above 5 core 150 mm² STA armoured cable’s structure,which has many advantages,as follow:
1. Safety
The 5 core 150 mm² STA armoured cables are designed to give added safety benefits. The armor layer acts as an extra layer of insulation, reducing the danger of electrical shock and fire hazards. Normal cables do not offer this added safety feature.
2. Durability
Sta armoured cables are generally more durable than normal cables. The extra layer of protection makes them more resistant to damage from external factors and increases their lifespan. Normal cables are more prone to damage, particularly in severe environments.
3. Versatility
5 core sta armoured cables are more flexible than normal cables. They can be used in various applications, including power distribution, lighting, and communications. They are also suitable for use in underground, overhead, and outdoor installations. Normal cables are more limited in their applications.
Please feel free to contact us if you have any questions.
Send Email
Place of Origin： Henan, China
Brand Name： HUADONG
Standard： BS IEC ASTM DIN
Voltage： 0.6/1kV
Number of cores： 5 Core
Conductor Material： Copper
Insulation Material： XLPE
Sectional area： 150mm²
Armouring material： Galvanized steel tape armoured
Operating temperature： 0°C – 90°C
Warranty： 100%quanlified
MOQ： 100M
Price： Get within 12 hours
5 core 150 mm² STA armoured cables represent a significant advancement in the field of electrical engineering, created to supply boosted safety and protection in demanding industries and environments. Consisting of various elements like conductors, insulation, bedding, armour, and sheath, these power transmission linchpins are constructed with careful attention to detail to ensure ideal durability and reliability.
The interior structure of the 5-core sta armored cable includes several layers to avoid damage to the cable. The outer sheath protects against rodents, abrasion and twisting and is usually made of plastic. Armoring materials are mainly derived from Kevlar, steel and aluminum foil, and are designed to protect the armored cable from being stretched during installation.
Due to above 5 core 150 mm² STA armoured cable’s Feature,which has many applications,as follow:
1. Oil and Gas Industry
The requiring conditions in the oil and gas sector require 5 core sta armoured cables that can endure excessive temperatures, pressure, and exposure to chemicals. 5 core sta armoured electrical cables, with their robust design, are well-suited for this industry, guaranteeing a reliable power supply in challenging environments such as offshore drilling rigs and oil refineries.
2. Industrial Settings
The 5 core 150 mm² STA armoured cables get comprehensive use in industrial environments where they serve as lifelines for machinery and equipment. The rugged construction of these cables guarantees they can withstand the rough conditions often current in industrial settings, including exposure to chemicals, wetness, and physical influence.
3. Commercial Buildings
150 mm² STA armoured cable are commonly employed in commercial buildings for their ability to provide a secure and reliable power distribution network. From office complexes to shopping malls, these cables guarantee a consistent power supply, contributing to the smooth functioning of various electrical systems.
When laying an 5 core 150 mm² STA armoured cable underground, the armoured electrical cable must be set out at an enough depth to prevent any prospective harm or disruption. It is better to consider enhancing the depth of direct burial underground or provide additional defense for the armoured cable to ensure security.It is a fact that BS standards do not state a single minimum depth, which is why it is necessary to ensure that the armoured electric cable will not be influenced by common activity.A minimum installation depth that’s followed by all experts is 450mm underground. This depth increases to 600mm for armoured cables in locations where there is a higher possibility for any potential disturbance.
If the 5 core sta armoured electrical cable is installed directly into the ground, the cable should be bordered by sharp sand to ensure it is protected against any damage to the sheath or insulation. Another precaution that can be taken is the use of electrical warning tape– this can be placed above the sand to suggest that there is an armoured electrical cable present below.
In the case of an armoured cable being installed within a pipeline, it is essential to ensure that it is completely watertight to prevent access of any kind.The armoured mains cable should also be earthed despite whether the armouring is being used as a protective conductor or not. What this does is make certain that the automation disconnection of supply (ADS) requirements are adhered to..Overlooking this may cause problems in the long run because an armoured cable that is not correctly earthed can become a dangerous security danger to users.
Please feel free to contact us if you have any questions.
